T+A PA 3100 HV — High-End Integrated Amplifier

Overview : The T+A PA 3100 HV represents the pinnacle of high-end integrated amplifiers. Its circuit design is built around T+A's High Voltage (HV) technology: by operating amplification stages at elevated voltage levels (+/- 85 Volts), transistors operate within their linear region, achieving tube-like warmth and harmonic purity without the distortion or reliability drawbacks of vacuum tubes. Supported by a massive 1500 Watt toroidal power transformer and extensive filtering capacitors, the PA 3100 HV delivers 2 × 500 Watts into 4 Ohms with instant current delivery. Its inner aluminum compartmentalized layout completely insulates the preamplifier, power supply, and output stages. Backlit front-panel VU meters provide real-time power monitoring.

Key Features :

• Power Output: 2 × 500 W into 4 Ω / 2 × 300 W into 8 Ω

• Topology: Fully balanced High Voltage design, Class A preamplifier

• Power Supply: Shielded 1500 W toroidal transformer

• Expandability: Internal slots for optional MM/MC Phono modules and APM board

• Weight: 38 kg
